Product Introduction

Part No.

Note:

●TL-101Y can only control damper to open and close.

●When the temperature reaches the set-point, thermostat will close the valve but the fan speed will be still running for DA model,thermostat will close the valve and stop the fan running for DB model.

Available for

●Two-pipe Fan coil unit

●Four-pipe Fan coil unit

●Motorized valve

●Air-damper

Technical Data

●Power Voltage: AC24V/AC110V/ AC210~230V, 50/60HZ. (Optional)

●Electrical Rating<3A

● Accuracy: ±1ºC.

●Set-point Range: 5ºC - 37ºC.

●Power Consumption: <1.5W.

●Sensor: NTC.

●Relative Humidity :< 92 %( no condensing)

●Dimension: 124*78*34mm (H*W*D).

Features

●Elegant shape with high reliability

●International used LCD screen display: shows easy to operate.

●Manual switch to select work state

●Thermostats can be directly mounted on the wall or standard wiring box.

Fuction

●COOL/ HEAT/OFF select by switch .

●Fan speed selected by switch. Fan speed: automatic, high, medium and low.

●Detect room temperature every 10seconds and show accuracy on LCD screen

●Memory mode to reset to previous conditions. (Optional).

If the power occurs to be cut off suddenly, the thermostats could be continuing to work by order if the power returns. The function is popular at Hotel, System House etc.

●Low Temperature Protection: auto start at temperature below 5℃, prevent frostbite.
